Description
California waters are rarely consistent—Pacific swell offshore, afternoon wind chop near the coast, and nonstop wake action in busy harbors can make even a capable planing yacht feel unsettled. The HS100 Stabilizers (SE Stabilis Electra System) are designed to reduce roll and improve ride comfort at speed, helping your yacht stay more composed on coastal runs, island crossings, and day-to-day cruising throughout California.
The HS System is an evolution of the SE Stabilis Electra platform, engineered to suit all hull shapes and optimized for planing yachts. Key refinements include a more efficient fin profile to reduce resistance, upgraded electronics for faster stabilization response, and the capability to control integrated onboard systems—such as steering and intruders—alongside fin operation.
Built for Planing Performance in California Sea States
HS100 is designed to deliver reliable stabilization authority where it matters most—underway—so the yacht feels calmer and more controlled when conditions get active. Benefits include:
- Reduced roll for improved guest comfort on longer runs
- More stable ride through mixed swell and wind-driven chop
- Greater confidence at cruising speeds in changeable conditions
- Efficiency-minded fin design intended to lower drag while maintaining authority
Key System Advantages
- Evolution of SE Stabilis Electra, optimized for planing yachts
- Refined fin profile designed to reduce resistance
- Upgraded electronics for faster response and performance
- Integrated control capability for steering and intruder systems
- Heavy-duty construction built for long service life in marine environments
Engineering & Construction Details
HS100 is built around marine-grade components designed for strength, corrosion resistance, and dependable sealing:
- Fin connection: Precision machined oversized self-locking taper
- Shaft: 100 mm duplex stainless steel
- Actuator housing: High-strength ductile iron
- Bearings: Heavy-duty tapered roller bearings (upper and lower)
- Lower seal: Two double-lip seals for maximum seawater protection, accessible in a 316 stainless steel retainer
- Upper seal: Double-lip, spring-loaded seal for grease retention and protection against external contaminants
- Lubrication: Pre-packed water-resistant grease for lifetime maintenance-free service; reduction gearbox lubricated with mineral oil
- Fit & finish: Painted RAL 9016 and polished
HS100 Specifications
| Specification | HS100 |
|---|---|
| Model | HS100 |
| Actuator Weight (incl. electric motor) | 288 kg |
| Motor Type | Brushless with electromagnetic brake |
| Applicable Motor Rating | 7.0 kW |
| Standard Fin Size | 12.0 m² |
| Maximum Fin Rotational Speed | > 80 deg/s |
| Power Supply | 400V AC 3-phase or 200V AC 3-phase |
| Frequency | 50 Hz or 60 Hz |
| Maximum Absorption Underway* | — |
| Maximum Absorption At Anchor* | — |
*Power absorption values may vary by installation and operating conditions.
Why HS100 Makes Sense in California
For planing yachts operating along the California coast, HS100 is built to deliver fast, confident stabilization while keeping hydrodynamic resistance in check. With upgraded electronics, a refined fin profile, and heavy-duty mechanical construction, it’s a strong solution for owners who want a smoother ride, reduced fatigue onboard, and more comfortable cruising through the sea states California is known for.
